We consider a global coordinate system (GCS) with Cartesian canonical basis $\widehat{𝐱}$, $\widehat{𝐲}$, $\widehat{𝐳}$. The spherical unit vectors are defined as

	$\widehat{𝐫}(\theta ,\phi )$	$=\sin (\theta )\cos (\phi )\widehat{𝐱}+\sin (\theta )\sin (\phi )\widehat{𝐲}+\cos (\theta )\widehat{𝐳}$		(64)
	$\widehat{𝜽}(\theta ,\phi )$	$=\cos (\theta )\cos (\phi )\widehat{𝐱}+\cos (\theta )\sin (\phi )\widehat{𝐲}-\sin (\theta )\widehat{𝐳}$
	$\widehat{𝝋}(\theta ,\phi )$	$=-\sin (\phi )\widehat{𝐱}+\cos (\phi )\widehat{𝐲}.$

For an arbitrary unit norm vector $\widehat{𝐯}=(x,y,z)$, the zenith and azimuth angles $\theta$ and $\phi$ can be computed as

	$\theta$	$={\cos }^{-1}(z)$		(65)
	$\phi$	$=\text{atan2}(y,x)$

where $\text{atan2}(y,x)$ is the two-argument inverse tangent function [29]. As any vector uniquely determines $\theta$ and $\phi$, we sometimes also write $\widehat{𝜽}(\widehat{𝐯})$ and $\widehat{𝝋}(\widehat{𝐯})$ instead of $\widehat{𝜽}(\theta ,\phi )$ and $\widehat{𝝋}(\theta ,\phi )$.

A 3D rotation with yaw, pitch, and roll angles $\alpha$, $\beta$, and $\gamma$, respectively, is expressed by the matrix

$$𝐑(\alpha ,\beta ,\gamma )={𝐑}_z(\alpha ){𝐑}_y(\beta ){𝐑}_x(\gamma )$$

(66)

where ${𝐑}_z(\alpha )$, ${𝐑}_y(\beta )$, and ${𝐑}_x(\gamma )$ are rotation matrices around the $z$, $y$, and $x$ axes, respectively, which are defined as

	${𝐑}_z(\alpha )$			(67)
	${𝐑}_y(\beta )$
	${𝐑}_x(\gamma )$

A closed-form expression for $𝐑(\alpha ,\beta ,\gamma )$ can be found in [21, Sec. 7.1-4]. The inverse rotation is simply defined by ${𝐑}^{-1}(\alpha ,\beta ,\gamma )={𝐑}^{𝖳}(\alpha ,\beta ,\gamma )$. A vector $𝐱$ defined in a first coordinate system is represented in a second coordinate system rotated by $𝐑(\alpha ,\beta ,\gamma )$ with respect to the first one as ${𝐱}^{\prime }={𝐑}^{𝖳}(\alpha ,\beta ,\gamma )𝐱$. If a point in the first coordinate system has spherical angles $(\theta ,\phi )$, the corresponding angles $({\theta }^{\prime },{\phi }^{\prime })$ in the second coordinate system can be found to be

	${\theta }^{\prime }$	$={\cos }^{-1}\left({\widehat{𝐳}}^{𝖳}{𝐑}^{𝖳}(\alpha ,\beta ,\gamma )\widehat{𝐫}(\theta ,\phi )\right)$		(68)
	${\phi }^{\prime }$	$=\arg \left({\left(\widehat{𝐱}+j\widehat{𝐲}\right)}^{𝖳}{𝐑}^{𝖳}(\alpha ,\beta ,\gamma )\widehat{𝐫}(\theta ,\phi )\right).$

For a vector field ${𝐅}^{\prime }({\theta }^{\prime },{\phi }^{\prime })$ expressed in local spherical coordinates

$${𝐅}^{\prime }({\theta }^{\prime },{\phi }^{\prime })=F_{{\theta }^{\prime }}({\theta }^{\prime },{\phi }^{\prime }){\widehat{𝜽}}^{\prime }({\theta }^{\prime },{\phi }^{\prime })+F_{{\phi }^{\prime }}({\theta }^{\prime },{\phi }^{\prime }){\widehat{𝝋}}^{\prime }({\theta }^{\prime },{\phi }^{\prime })$$

(69)

that are rotated by $𝐑=𝐑(\alpha ,\beta ,\gamma )$ with respect to the GCS, the spherical field components in the GCS can be expressed as

(70)

so that

$$𝐅(\theta ,\phi )=F_{\theta }(\theta ,\phi )\widehat{𝜽}(\theta ,\phi )+F_{\phi }(\theta ,\phi )\widehat{𝝋}(\theta ,\phi ).$$

(71)

Sometimes, it is also useful to find the rotation matrix that maps a unit vector $\widehat{𝐚}$ to $\widehat{𝐛}$. This can be achieved with the help of Rodrigues’ rotation formula [30] which defines the matrix

$$𝐑(\widehat{𝐚},\widehat{𝐛})=𝐈+\sin (\theta )𝐊+(1-\cos (\theta )){𝐊}^2$$

(72)

where

	$𝐊$			(73)
	$\widehat{𝐤}$	$={\displaystyle \frac{\widehat{𝐚}\times \widehat{𝐛}}{{\parallel \widehat{𝐚}\times \widehat{𝐛}\parallel }_2}}$		(74)
	$\theta$	$={\widehat{𝐚}}^{𝖳}\widehat{𝐛}$		(75)

such that $𝐑(\widehat{𝐚}$, $\widehat{𝐛})\widehat{𝐚}=\widehat{𝐛}$.

A time-harmonic planar electric wave $𝐄(𝐱,t)\in {ℂ}^3$ traveling in a homogeneous medium with wave vector $𝐤\in {ℂ}^3$ can be described at position $𝐱\in {ℝ}^3$ and time $t$ as

	$𝐄(𝐱,t)$	$={𝐄}_0{e}^{j(\omega t-{𝐤}^{𝖧}𝐱)}$		(76)
		$=𝐄(𝐱)e^{j\omega t}$		(77)

where ${𝐄}_0\in {ℂ}^3$ is the field phasor. The wave vector can be decomposed as $𝐤=k\widehat{𝐤}$, where $\widehat{𝐤}$ is a unit norm vector, $k=\omega \sqrt{\epsilon \mu }$ is the wave number, and $\omega =2\pi f$ is the angular frequency. The permittivity $\epsilon$ and permeability $\mu$ are defined as

	$\epsilon$	$=\eta {\epsilon }_0$		(78)
	$\mu$	$={\mu }_r{\mu }_0$		(79)

where $\eta$ and ${\epsilon }_0$ are the complex relative and vacuum permittivities, ${\mu }_r$ and ${\mu }_0$ are the relative and vacuum permeabilities, and $\sigma$ is the conductivity. The complex relative permittivity $\eta$ is given as

$$\eta ={\epsilon }_r-j\frac{\sigma }{{\epsilon }_0\omega }$$

(80)

where ${\epsilon }_r$ is the real relative permittivity of a non-conducting dielectric.

With these definitions, the speed of light is given as [31, Eq. 4-28d]

$$c=\frac{1}{\sqrt{{\epsilon }_0{\epsilon }_r\mu }}{\left\{\frac{1}{2}\left(\sqrt{1+{\left(\frac{\sigma }{\omega {\epsilon }_0{\epsilon }_r}\right)}^2}+1\right)\right\}}^{-\frac{1}{2}}$$

(81)

where the factor in curly brackets vanishes for non-conducting materials. The speed of light in vacuum is denoted $c_0=\frac{1}{\sqrt{{\epsilon }_0{\mu }_0}}$ and the vacuum wave number $k_0=\frac{\omega }{c_0}$. In conducting materials, the wave number is complex which translates to propagation losses.

The associated magnetic field $𝐇(𝐱,t)\in {ℂ}^3$ is

$$𝐇(𝐱,t)=\frac{\widehat{𝐤}\times 𝐄(𝐱,t)}{Z}=𝐇(𝐱)e^{j\omega t}$$

(82)

where $Z=\sqrt{\mu /\epsilon }$ is the wave impedance. The vacuum impedance is denoted by $Z_0=\sqrt{{\mu }_0/{\epsilon }_0}\approx 376.73\mathrm{\Omega }$.

The time-averaged Poynting vector is defined as

$$𝐒(𝐱)=\frac{1}{2}\mathrm{\Re }\left\{𝐄(𝐱)\times 𝐇(𝐱)\right\}=\frac{1}{2}\mathrm{\Re }\left\{\frac{1}{Z}\right\}{\parallel 𝐄(𝐱)\parallel }_2^2\widehat{𝐤}$$

(83)

which describes the directional energy flux [$\mathrm{W}{\mathrm{m}}^{-2}$], i.e. energy transfer per unit area per unit time. Note that the actual electromagnetic waves are the real parts of $𝐄(𝐱,t)$ and $𝐇(𝐱,t)$.

We assume that the electric far field of an antenna in free space can be described by a spherical wave originating from the center of the antenna:

$$𝐄(r,\theta ,\phi ,t)=𝐄(r,\theta ,\phi )e^{j\omega t}={𝐄}_0(\theta ,\phi )\frac{e^{-j{k}_{0}r}}{r}{e}^{j\omega t}$$

(84)

where ${𝐄}_0(\theta ,\phi )$ is the electric field phasor, $r$ is the distance (or radius), $\theta$ the zenith angle, and $\phi$ the azimuth angle. In contrast to a planar wave, the field strength decays as $1/r$.

The complex antenna field pattern $𝐅(\theta ,\phi )$ is defined as

$𝐅(\theta ,\phi )={\displaystyle \frac{{𝐄}_0(\theta ,\phi )}{{\max }_{\theta ,\phi }{\parallel {𝐄}_0(\theta ,\phi )\parallel }_2}}.$

(85)

The time-averaged Poynting vector for such a spherical wave is

$$𝐒(r,\theta ,\phi )=\frac{1}{2Z_0}{\parallel 𝐄(r,\theta ,\phi )\parallel }_2^2\widehat{𝐫}$$

(86)

where $\widehat{𝐫}$ is the radial unit vector. It simplifies for an ideal isotropic antenna with input power $P_{\text{T}}$ to

$${𝐒}_{\text{iso}}(r,\theta ,\phi )=\frac{P_{\text{T}}}{4\pi r^2}\widehat{𝐫}.$$

(87)

The antenna gain $G$ is the ratio of the maximum radiation power density of the antenna in radial direction and that of an ideal isotropic radiating antenna:

$$G=\frac{{\max }_{\theta ,\phi }{\parallel 𝐒(r,\theta ,\phi )\parallel }_2}{{\parallel {𝐒}_{\text{iso}}(r,\theta ,\phi )\parallel }_2}=\frac{2\pi }{Z_0{P}_{\text{T}}}\underset{\theta ,\phi }{\max }{\parallel {𝐄}_0(\theta ,\phi )\parallel }_2^2.$$

(88)

One can similarly define a gain with directional dependency by ignoring the computation of the maximum the last equation:

$$G(\theta ,\phi )=\frac{2\pi }{Z_0{P}_{\text{T}}}{\parallel {𝐄}_0(\theta ,\phi )\parallel }_2^2=G{\parallel 𝐅(\theta ,\phi )\parallel }_2^2.$$

(89)

If one uses in the last equation the radiated power $P={\eta }_{\text{rad}}{P}_{\text{T}}$, where ${\eta }_{\text{rad}}$ is the radiation efficiency, instead of the input power $P_{\text{T}}$, one obtains the directivity $D(\theta ,\phi )$. Both are related through $G(\theta ,\phi )={\eta }_{\text{rad}}D(\theta ,\phi )$.

Combining $F$ and $G$, we can obtain the following expression of the electric far field

$${𝐄}_{\text{T}}(r,{\theta }_{\text{T}},{\phi }_{\text{T}})=\sqrt{\frac{P_{\text{T}}{G}_{\text{T}}{Z}_0}{2\pi }}\frac{e^{-j{k}_{0}r}}{r}{𝐅}_{\text{T}}({\theta }_{\text{T}},{\phi }_{\text{T}})$$

(92)

where we have added the subscript T to all quantities that are specific to the transmitting antenna.

The input power $P_{\text{T}}$ of an antenna with (conjugate matched) impedance $Z_{\text{T}}$, fed by a voltage source with complex amplitude $V_{\text{T}}$, is given by (see e.g., [32]).

$$P_{\text{T}}=\frac{{|V_{\text{T}}|}^2}{8\mathrm{\Re }\{Z_{\text{T}}\}}.$$

(93)

Although the transmitting antenna radiates a spherical wave ${𝐄}_{\text{T}}(r,{\theta }_{\text{T}},{\phi }_{\text{T}})$, we assume that the receiving antenna observes a planar incoming wave ${𝐄}_{\text{R}}$ that arrives from the angles ${\theta }_{\text{R}}$ and ${\phi }_{\text{R}}$ which are defined in the local spherical coordinates of the receiving antenna. The Poynting vector of the incoming wave ${𝐒}_{\text{R}}$ is hence (86)

$${𝐒}_{\text{R}}=-\frac{1}{2Z_0}{\parallel {𝐄}_{\text{R}}\parallel }_2^2\widehat{𝐫}({\theta }_{\text{R}},{\phi }_{\text{R}})$$

(98)

where $\widehat{𝐫}({\theta }_{\text{R}},{\phi }_{\text{R}})$ is the radial unit vector in the spherical coordinate system of the receiver.

The aperture or effective area $A_{\text{R}}$ of an antenna with gain $G_{\text{R}}$ is defined as the ratio of the available received power $P_{\text{R}}$ at the output of the antenna and the absolute value of the Poynting vector, i.e. the power density:

$$A_{\text{R}}=\frac{P_{\text{R}}}{{\parallel {𝐒}_{\text{R}}\parallel }_2}=G_{\text{R}}\frac{{\lambda }^2}{4\pi }$$

(99)

where $\frac{{\lambda }^2}{4\pi }$ is the aperture of an isotropic antenna. In the definition above, it is assumed that the antenna is ideally directed towards and polarization matched to the incoming wave. For an arbitrary orientation of the antenna (but still assuming polarization matching), we can define a direction dependent effective area

$$A_{\text{R}}({\theta }_{\text{R}},{\phi }_{\text{R}})=G_{\text{R}}({\theta }_{\text{R}},{\phi }_{\text{R}})\frac{{\lambda }^2}{4\pi }.$$

(100)

The available received power at the output of the antenna can be expressed as

$$P_{\text{R}}=\frac{{|V_{\text{R}}|}^2}{8\mathrm{\Re }\{Z_{\text{R}}\}}$$

(101)

where $Z_{\text{R}}$ is the impedance of the receiving antenna and $V_{\text{R}}$ the open circuit voltage. We can now combine (101), (100), and (99) to obtain the following expression for the absolute value of the voltage $|V_{\text{R}}|$ assuming matched polarization:

	$|V_{\text{R}}|$	$=\sqrt{P_{\text{R}}8\mathrm{\Re }\{Z_{\text{R}}\}}$		(102)
		$=\sqrt{{\displaystyle \frac{{\lambda }^2}{4\pi }}{G}_{\text{R}}({\theta }_{\text{R}},{\phi }_{\text{R}}){\displaystyle \frac{8\mathrm{\Re }\{Z_{\text{R}}\}}{2Z_0}}{\parallel {𝐄}_{\text{R}}\parallel }_2^2}$		(103)
		$=\sqrt{{\displaystyle \frac{{\lambda }^2}{4\pi }}{G}_{\text{R}}{\displaystyle \frac{4\mathrm{\Re }\{Z_{\text{R}}\}}{Z_0}}}{\parallel {𝐅}_{\text{R}}({\theta }_{\text{R}},{\phi }_{\text{R}})\parallel }_2{\parallel {𝐄}_{\text{R}}\parallel }_2.$		(104)

By extension of the previous equation, we can obtain an expression for $V_{\text{R}}$ which is valid for arbitrary polarizations of the incoming wave and the receiving antenna:

$$V_{\text{R}}=\sqrt{\frac{{\lambda }^2}{4\pi }{G}_{\text{R}}\frac{4\mathrm{\Re }\{Z_{\text{R}}\}}{Z_0}}{𝐅}_{\text{R}}{({\theta }_{\text{R}},{\phi }_{\text{R}})}^{𝖧}{𝐄}_{\text{R}}.$$

(105)

A single propagation path consists of a sequence of scattering processes, where a scattering process can be anything that prevents the wave from propagating as in free space. This includes specular reflection, refraction, diffraction, and diffuse reflection. For each scattering process, one needs to compute a relationship between the incoming field at the scatter center and the created far field at the next scatter center or the receiving antenna. We can represent this cascade of scattering processes by a single matrix $\widetilde{𝐓}$ that describes the transformation that the radiated field ${𝐄}_{\text{T}}(r,{\theta }_{\text{T}},{\phi }_{\text{T}})$ undergoes until it reaches the receiving antenna:

$${𝐄}_{\text{R}}=\sqrt{\frac{P_{\text{T}}{G}_{\text{T}}{Z}_0}{2\pi }}\widetilde{𝐓}{𝐅}_{\text{T}}({\theta }_{\text{T}},{\phi }_{\text{T}}).$$

(108)

Note that we have obtained this expression by replacing the free space propagation term $\frac{e^{-j{k}_{0}r}}{r}$ in (92) by the matrix $\widetilde{𝐓}$. This requires that all quantities are expressed in the same coordinate system which is also assumed in the following expressions. Further, it is assumed that the matrix $\widetilde{𝐓}$ includes the necessary coordinate transformations. In some cases, e.g., for diffuse reflection (see (168) in Section A.9), the matrix $\widetilde{𝐓}$ depends on the incoming field and is not a linear transformation.

Plugging (108) into (105), we can obtain a general expression for the received voltage of a propagation path:

$$V_{\text{R}}=\sqrt{{\left(\frac{\lambda }{4\pi }\right)}^2{G}_{\text{R}}{G}_{\text{T}}{P}_{\text{T}}8\mathrm{\Re }\{Z_{\text{R}}\}}{𝐅}_{\text{R}}{({\theta }_{\text{R}},{\phi }_{\text{R}})}^{𝖧}\widetilde{𝐓}{𝐅}_{\text{T}}({\theta }_{\text{T}},{\phi }_{\text{T}}).$$

(109)

If the electromagnetic wave arrives at the receiving antenna over $N$ propagation paths, we can simply add the received voltages from all paths to obtain

	$V_{\text{R}}$	$=\sqrt{{\left({\displaystyle \frac{\lambda }{4\pi }}\right)}^2{G}_{\text{R}}{G}_{\text{T}}{P}_{\text{T}}8\mathrm{\Re }\{Z_{\text{R}}\}}{\displaystyle \sum _{n=1}^N}{𝐅}_{\text{R}}{({\theta }_{\text{R},i},{\phi }_{\text{R},i})}^{𝖧}{\widetilde{𝐓}}_i{𝐅}_{\text{T}}({\theta }_{\text{T},i},{\phi }_{\text{T},i})$		(110)
		$=\sqrt{{\left({\displaystyle \frac{\lambda }{4\pi }}\right)}^2{P}_{\text{T}}8\mathrm{\Re }\{Z_{\text{R}}\}}{\displaystyle \sum _{n=1}^N}{𝐂}_{\text{R}}{({\theta }_{\text{R},i},{\phi }_{\text{R},i})}^{𝖧}{\widetilde{𝐓}}_i{𝐂}_{\text{T}}({\theta }_{\text{T},i},{\phi }_{\text{T},i})$		(111)

where all path-dependent quantities carry the subscript $i$. Note that the matrices ${\widetilde{𝐓}}_i$ also ensure appropriate scaling so that the total received power can never be larger than the transmit power.

The channel frequency response $H(f)$ at frequency $f=\frac{c}{\lambda }$ is defined as the ratio between the received voltage and the voltage at the input to the transmitting antenna:

$$H(f)=\frac{V_{\text{R}}}{V_{\text{T}}}=\frac{V_{\text{R}}}{|V_{\text{T}}|}$$

(112)

where it is assumed that the input voltage has zero phase.

It is useful to separate phase shifts due to wave propagation from the transfer matrices ${\widetilde{𝐓}}_i$. If we denote by $r_i$ the total length of path $i$ with average propagation speed $c_i$, the path delay is ${\tau }_i=r_i/c_i$. We can now define the new transfer matrix

$${𝐓}_i={\widetilde{𝐓}}_i{e}^{j2\pi f{\tau }_i}.$$

(113)

Using (93) and (113) in (110) while assuming equal real parts of both antenna impedances, i.e. $\mathrm{\Re }\{Z_{\text{T}}\}=\mathrm{\Re }\{Z_{\text{R}}\}$ (which is typically the case), we obtain the final expression for the channel frequency response:

$$\boxed{H(f)=\sum _{i=1}^N\underset{\triangleq a_i}{\underbrace{\frac{\lambda }{4\pi }{𝐂}_{\text{R}}{({\theta }_{\text{R},i},{\phi }_{\text{R},i})}^{𝖧}{𝐓}_i{𝐂}_{\text{T}}({\theta }_{\text{T},i},{\phi }_{\text{T},i})}}{e}^{-j2\pi f{\tau }_i}}$$

(114)

Taking the inverse Fourier transform, we finally obtain the channel impulse response

$$\boxed{h(\tau )={\int }_{-\mathrm{\infty }}^{\mathrm{\infty }}H(f)e^{j2\pi f\tau }𝑑f=\sum _{i=1}^N{a}_i\delta (\tau -{\tau }_i)}$$

(115)

The baseband equivalent channel impulse response is then defined as [25, Eq. 2.28]:

$$h_{\text{b}}(\tau )=\sum _{i=1}^N\underset{\triangleq a_i^{\text{b}}}{\underbrace{a_i{e}^{-j2\pi f{\tau }_i}}}\delta (\tau -{\tau }_i).$$

(116)

When a plane wave hits a plane interface which separates two materials, e.g., air and concrete, a part of the wave gets reflected and the other refracted, i.e. it propagates into the other material. We assume in the following description that both materials are uniform non-magnetic dielectrics, i.e. ${\mu }_r=1$, and follow the definitions as in [33]. The incoming wave phasor ${𝐄}_{\text{i}}$ is expressed by two arbitrary orthogonal polarization components, i.e.

$${𝐄}_{\text{i}}=E_{\text{i},s}{\widehat{𝐞}}_{\text{i},s}+E_{\text{i},p}{\widehat{𝐞}}_{\text{i},p}$$

(117)

which are both orthogonal to the incident wave vector, i.e. ${\widehat{𝐞}}_{\text{i},s}^{𝖳}{\widehat{𝐞}}_{\text{i},p}={\widehat{𝐞}}_{\text{i},s}^{𝖳}{\widehat{𝐤}}_{\text{i}}={\widehat{𝐞}}_{\text{i},p}^{𝖳}{\widehat{𝐤}}_{\text{i}}=0$.

Figure 31 shows reflection and refraction of the incoming wave at the plane interface between two materials with relative permittivities ${\eta }_1$ and ${\eta }_2$. The coordinate system is chosen such that the wave vectors of the incoming, reflected, and transmitted waves lie within the plane of incidence, which is chosen to be the x-z plane. The normal vector of the interface $\widehat{𝐧}$ is pointing toward the negative z axis. The incoming wave is must be represented in a different basis, i.e. in the form two different orthogonal polarization components $E_{\text{i},⟂}$ and $E_{\text{i},\parallel }$, i.e.

$${𝐄}_{\text{i}}=E_{\text{i},⟂}{\widehat{𝐞}}_{\text{i},⟂}+E_{\text{i},\parallel }{\widehat{𝐞}}_{\text{i},\parallel }$$

(118)

where the former is orthogonal to the plane of incidence and called transverse electric (TE) polarization (left), and the latter is parallel to the plane of incidence and called transverse magnetic (TM) polarization (right). In the following, we adopt the convention that all transverse components are coming out of the figure (indicated by the $\odot$ symbol). One can easily verify that the following relationships must hold:

	${\widehat{𝐞}}_{\text{i},⟂}$	$={\displaystyle \frac{{\widehat{𝐤}}_{\text{i}}\times \widehat{𝐧}}{{\parallel {\widehat{𝐤}}_{\text{i}}\times \widehat{𝐧}\parallel }_2}}$		(119)
	${\widehat{𝐞}}_{\text{i},\parallel }$	$={\widehat{𝐞}}_{\text{i},⟂}\times {\widehat{𝐤}}_{\text{i}}$
	$\left[\begin{array}{c}{E}_{\text{i},⟂}\\ E_{\text{i},\parallel }\end{array}\right]$

where we have defined the following matrix-valued function

(120)

While the angles of incidence and reflection are both equal to ${\theta }_1$, the angle of the refracted wave ${\theta }_2$ is given by Snell’s law

$$\sin ({\theta }_2)=\sqrt{\frac{{\eta }_1}{{\eta }_2}}\sin ({\theta }_1)$$

(121)

or, equivalently,

$$\cos ({\theta }_2)=\sqrt{1-\frac{{\eta }_1}{{\eta }_2}{\sin }^2({\theta }_1)}.$$

(122)

The reflected and transmitted wave phasors ${𝐄}_{\text{r}}$ and ${𝐄}_{\text{t}}$ are similarly represented as

	${𝐄}_{\text{r}}$	$=E_{\text{r},⟂}{\widehat{𝐞}}_{\text{r},⟂}+E_{\text{r},\parallel }{\widehat{𝐞}}_{\text{r},\parallel }$		(123)
	${𝐄}_{\text{t}}$	$=E_{\text{t},⟂}{\widehat{𝐞}}_{\text{t},⟂}+E_{\text{t},\parallel }{\widehat{𝐞}}_{\text{t},\parallel }$		(124)

where

	${\widehat{𝐞}}_{\text{r},⟂}$	$={\widehat{𝐞}}_{\text{i},⟂}$		(125)
	${\widehat{𝐞}}_{\text{r},\parallel }$	$={\displaystyle \frac{{\widehat{𝐞}}_{\text{r},⟂}\times {\widehat{𝐤}}_{\text{r}}}{{\parallel {\widehat{𝐞}}_{\text{r},⟂}\times {\widehat{𝐤}}_{\text{r}}\parallel }_2}}$
	${\widehat{𝐞}}_{\text{t},⟂}$	$={\widehat{𝐞}}_{\text{i},⟂}$
	${\widehat{𝐞}}_{\text{t},\parallel }$	$={\displaystyle \frac{{\widehat{𝐞}}_{\text{t},⟂}\times {\widehat{𝐤}}_{\text{t}}}{{\parallel {\widehat{𝐞}}_{\text{t},⟂}\times {\widehat{𝐤}}_{\text{t}}\parallel }_2}}$

and

	${\widehat{𝐤}}_{\text{r}}$	$={\widehat{𝐤}}_{\text{i}}-2\left({\widehat{𝐤}}_{\text{i}}^{𝖳}\widehat{𝐧}\right)\widehat{𝐧}$		(126)
	${\widehat{𝐤}}_{\text{t}}$	$=\sqrt{{\displaystyle \frac{{\eta }_1}{{\eta }_2}}}{\widehat{𝐤}}_{\text{i}}+\left(\sqrt{{\displaystyle \frac{{\eta }_1}{{\eta }_2}}}\cos ({\theta }_1)-\cos ({\theta }_2)\right)\widehat{𝐧}.$

The Fresnel equations provide relationships between the incident, reflected, and refracted field components for :

	$r_{⟂}$	$={\displaystyle \frac{E_{\text{r},⟂}}{E_{\text{i},⟂}}}={\displaystyle \frac{\sqrt{{\eta }_1}\cos ({\theta }_1)-\sqrt{{\eta }_2}\cos ({\theta }_2)}{\sqrt{{\eta }_1}\cos ({\theta }_1)+\sqrt{{\eta }_2}\cos ({\theta }_2)}}$		(127)
	$r_{\parallel }$	$={\displaystyle \frac{E_{\text{r},\parallel }}{E_{\text{i},\parallel }}}={\displaystyle \frac{\sqrt{{\eta }_2}\cos ({\theta }_1)-\sqrt{{\eta }_1}\cos ({\theta }_2)}{\sqrt{{\eta }_2}\cos ({\theta }_1)+\sqrt{{\eta }_1}\cos ({\theta }_2)}}$
	$t_{⟂}$	$={\displaystyle \frac{E_{\text{t},⟂}}{E_{\text{i},⟂}}}={\displaystyle \frac{2\sqrt{{\eta }_1}\cos ({\theta }_1)}{\sqrt{{\eta }_1}\cos ({\theta }_1)+\sqrt{{\eta }_2}\cos ({\theta }_2)}}$
	$t_{\parallel }$	$={\displaystyle \frac{E_{\text{t},\parallel }}{E_{\text{i},\parallel }}}={\displaystyle \frac{2\sqrt{{\eta }_1}\cos ({\theta }_1)}{\sqrt{{\eta }_2}\cos ({\theta }_1)+\sqrt{{\eta }_1}\cos ({\theta }_2)}}.$

If $\sqrt{\left|{\eta }_1/{\eta }_2\right|}\sin ({\theta }_1)\ge 1$, we have $r_{⟂}=r_{\parallel }=1$ and $t_{⟂}=t_{\parallel }=0$, i.e. total reflection. For the case of an incident wave in vacuum, i.e. ${\eta }_1=1$, the Fresnel equations (127) simplify to

	$r_{⟂}$	$={\displaystyle \frac{\cos ({\theta }_1)-\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}{\cos ({\theta }_1)+\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}}$		(128)
	$r_{\parallel }$	$={\displaystyle \frac{{\eta }_2\cos ({\theta }_1)-\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}{{\eta }_2\cos ({\theta }_1)+\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}}$
	$t_{⟂}$	$={\displaystyle \frac{2\cos ({\theta }_1)}{\cos ({\theta }_1)+\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}}$
	$t_{\parallel }$	$={\displaystyle \frac{2\sqrt{{\eta }_2}\cos ({\theta }_1)}{{\eta }_2\cos ({\theta }_1)+\sqrt{{\eta }_2-{\sin }^2({\theta }_1)}}}.$

Putting everything together, we obtain the following relationships between incident, reflected, and transmitted waves:

	$\left[\begin{array}{c}{E}_{\text{r},⟂}\\ E_{\text{r},\parallel }\end{array}\right]$			(129)
	$\left[\begin{array}{c}{E}_{\text{t},⟂}\\ E_{\text{t},\parallel }\end{array}\right]$			(130)

While modern geometrical optics (GO) [34, 35] can accurately describe phase and polarization properties of electromagnetic fields undergoing reflection and refraction (transmission) as described above, they fail to account for the phenomenon of diffraction, e.g., bending of waves around corners. This leads to the undesired and physically incorrect effect that the field abruptly falls to zero at geometrical shadow boundaries (for incident and reflected fields).

Joseph Keller presented in [10] a method which allowed the incorporation of diffraction into GO which is known as the geometrical theory of diffraction (GTD). He introduced the notion of diffracted rays that follow the law of edge diffraction, i.e., the diffracted and incident rays make the same angle with the edge at the point of diffraction and lie on opposite sides of the plane normal to the edge. The GTD suffers, however from several shortcomings, most importantly the fact that the diffracted field is infinite at shadow boundaries.

The uniform theory of diffraction (UTD) [36] alleviates this problem and provides solutions that are uniformly valid, even at shadow boundaries. For a great introduction to the UTD, we refer to [12]. While [36] deals with diffraction at edges of perfectly conducting surfaces, it was heuristically extended to finitely conducting wedges in [37]. This solution, which is also recomended by the ITU [38], is implemented in Sionna. However, both [37] and [38] only deal with two-dimensional scenes where source and observation lie in the same plane, orthogonal to the edge. We will provide below the three-dimensional version of [37], following the defintitions of [12, Ch. 6]. A similar result can be found, e.g., in [39, Eq. 6-29–6-39].

We consider an infinitely long wedge with unit norm edge vector $\widehat{𝐞}$, as shown in Figure 33. An incident ray of a spherical wave with field phasor ${𝐄}_i(S^{\prime })$ at point $S^{\prime }$ propagates in the direction ${\widehat{𝐬}}^{\prime }$ and is diffracted at point $Q_d$ on the edge. The diffracted ray of interest (there are infinitely many on Keller’s cone) propagates in the direction $\widehat{𝐬}$ towards the point of observation $S$. We denote by $s^{\prime }={\parallel S^{\prime }-Q_d\parallel }_2$ and $s={\parallel Q_d-S\parallel }_2$ the lengths of the incident and diffracted path segments, respectively. By the law of edge diffraction, the angles ${\beta }_0^{\prime }$ and ${\beta }_0$ between the edge and the incident and diffracted rays, respectively, satisfy:

$$\cos \left({\beta }_0^{\prime }\right)=\left|{\widehat{𝐬}}^{\prime \text{T}}\widehat{𝐞}\right|=\left|{\widehat{𝐬}}^{𝖳}\widehat{𝐞}\right|=\cos ({\beta }_0).$$

(134)

To be able to express the diffraction coefficients as a 2x2 matrix—similar to what is done for reflection and refraction—the incident field must be resolved into two components $E_{i,{\varphi }^{\prime }}$ and $E_{i,{\beta }_0^{\prime }}$, the former orthogonal and the latter parallel to the edge-fixed plane of incidence, i.e., the plane containing $\widehat{𝐞}$ and ${\widehat{𝐬}}^{\prime }$. The diffracted field is then represented by two components $E_{d,\varphi }$ and $E_{d,{\beta }_0}$ that are respectively orthogonal and parallel to the edge-fixed plane of diffraction, i.e., the plane containing $\widehat{𝐞}$ and $\widehat{𝐬}$. The corresponding component unit vectors are defined as

	${\widehat{\mathit{\varphi }}}^{\prime }$	$={\displaystyle \frac{{\widehat{𝐬}}^{\prime }\times \widehat{𝐞}}{{\parallel {\widehat{𝐬}}^{\prime }\times \widehat{𝐞}\parallel }_2}}$		(135)
	${\widehat{𝜷}}_0^{\prime }$	$={\widehat{\mathit{\varphi }}}^{\prime }\times {\widehat{𝐬}}^{\prime }$		(136)
	$\widehat{\mathit{\varphi }}$	$=-{\displaystyle \frac{\widehat{𝐬}\times \widehat{𝐞}}{{\parallel \widehat{𝐬}\times \widehat{𝐞}\parallel }_2}}$		(137)
	${\widehat{𝜷}}_0$	$=\widehat{\mathit{\varphi }}\times \widehat{𝐬}.$		(138)

Figure 34 shows the top view on the wedge that we need for some additional definitions.

The wedge has two faces called 0-face and n-face, respectively, with surface normal vectors ${\widehat{𝐧}}_0$ and ${\widehat{𝐧}}_n$. The exterior wedge angle is $n\pi$, with $1\le n\le 2$. Note that the surfaces are chosen such that $\widehat{𝐞}={\widehat{𝐧}}_0\times {\widehat{𝐧}}_n$. For $n=2$, the wedge reduces to a screen and the choice of the 0-face and n-face is arbitrary as they point in opposite directions.

The incident and diffracted rays have angles ${\varphi }^{\prime }$ and $\varphi$ measured with respect to the 0-face in the plane perpendicular to the edge. They can be computed as follows:

	${\varphi }^{\prime }$	$=\pi -\left[\pi -\arccos \left(-{\widehat{𝐬}}_t^{\prime \text{T}}{\widehat{𝐭}}_0\right)\right]\mathrm{sgn}\left(-{\widehat{𝐬}}_t^{\prime \text{T}}{\widehat{𝐧}}_0\right)$		(139)
	$\varphi$	$=\pi -\left[\pi -\arccos \left({\widehat{𝐬}}_t^{𝖳}{\widehat{𝐭}}_0\right)\right]\mathrm{sgn}\left({\widehat{𝐬}}_t^{𝖳}{\widehat{𝐧}}_0\right)$		(140)

where

	${\widehat{𝐭}}_0$	$={\widehat{𝐧}}_0\times \widehat{𝐞}$		(141)
	${\widehat{𝐬}}_t^{\prime }$	$={\displaystyle \frac{{\widehat{𝐬}}^{\prime }-\left({\widehat{𝐬}}^{\prime \text{T}}\widehat{𝐞}\right)\widehat{𝐞}}{{\parallel {\widehat{𝐬}}^{\prime }-\left({\widehat{𝐬}}^{\prime \text{T}}\widehat{𝐞}\right)\widehat{𝐞}\parallel }_2}}$		(142)
	${\widehat{𝐬}}_t$	$={\displaystyle \frac{\widehat{𝐬}-\left({\widehat{𝐬}}^{𝖳}\widehat{𝐞}\right)\widehat{𝐞}}{{\parallel \widehat{𝐬}-\left({\widehat{𝐬}}^{𝖳}\widehat{𝐞}\right)\widehat{𝐞}\parallel }_2}}$		(143)

are the unit vector tangential to the 0-face, as well as the unit vectors pointing in the directions of ${\widehat{𝐬}}^{\prime }$ and $\widehat{𝐬}$, projected on the plane perpendicular to the edge, respectively. The function $\text{sgn}(x)$ is defined in this context as

(144)

With these definitions, the diffracted field at point $\mathrm{`}S\mathrm{`}$ can be computed from the incoming field at point $\mathrm{`}{S}^{\prime }$ as follows:

$\left[\begin{array}{c}{E}_{d,\varphi }\\ E_{d,{\beta }_0}\end{array}\right](S)=-\left(\left(D_1+D_2\right)𝐈-D_3{𝐑}_n-D_4{𝐑}_0\right)\left[\begin{array}{c}{E}_{i,{\varphi }^{\prime }}\\ E_{i,{\beta }_0^{\prime }}\end{array}\right](S^{\prime })\sqrt{{\displaystyle \frac{1}{s^{\prime }s(s^{\prime }+s)}}}{e}^{-jk(s^{\prime }+s)}$

(145)

where $k=2\pi /\lambda$ is the wave number and the matrices ${𝐑}_{\nu },\nu \in [0,n]$, are given as

(146)

with $𝐖(\cdot )$ as defined in (120), where $r_{⟂}({\theta }_{r,\nu },{\eta }_{\nu })$ and $r_{\parallel }({\theta }_{r,\nu },{\eta }_{\nu })$ are the Fresnel reflection coefficents from (128), evaluated for the complex relative permittivities ${\eta }_{\nu }$ and angles ${\theta }_{r_{,}\nu }$ with cosines

	$\cos \left({\theta }_{r,0}\right)$	$=\left|\sin ({\varphi }^{\prime })\right|$		(147)
	$\cos \left({\theta }_{r,n}\right)$	$=\left|\sin (n\pi -\varphi )\right|.$		(148)

and where

	${\widehat{𝐞}}_{i,⟂,\nu }$	$={\displaystyle \frac{{\widehat{𝐬}}^{\prime }\times {\widehat{𝐧}}_{\nu }}{{\parallel {\widehat{𝐬}}^{\prime }\times {\widehat{𝐧}}_{\nu }\parallel }_2}}$		(149)
	${\widehat{𝐞}}_{i,\parallel ,\nu }$	$={\widehat{𝐞}}_{i,⟂,\nu }\times {\widehat{𝐬}}^{\prime }$		(150)
	${\widehat{𝐞}}_{r,⟂,\nu }$	$={\widehat{𝐞}}_{i,⟂,\nu }$		(151)
	${\widehat{𝐞}}_{r,\parallel ,\nu }$	$={\widehat{𝐞}}_{i,⟂,\nu }\times \widehat{𝐬}$		(152)

as already defined in (119) and (125), but made explicit here for the case of diffraction. The matrices ${𝐑}_{\nu }$ simply describe the reflected field from both surfaces in the basis used for the description of the diffraction process. Note that the absolute value is used in (147) to account for virtual reflections from shadowed surfaces, see the discussion in [12, p.185]. The diffraction coefficients $D_1,\mathrm{\dots },D_4$ are computed as

	$D_1$	$={\displaystyle \frac{-e^{-\frac{j\pi }{4}}}{2n\sqrt{2\pi k}\sin ({\beta }_0)}}\text{cot}\left({\displaystyle \frac{\pi +(\varphi -{\varphi }^{\prime })}{2n}}\right)F\left(kL{a}^{+}(\varphi -{\varphi }^{\prime })\right)$		(153)
	$D_2$	$={\displaystyle \frac{-e^{-\frac{j\pi }{4}}}{2n\sqrt{2\pi k}\sin ({\beta }_0)}}\text{cot}\left({\displaystyle \frac{\pi -(\varphi -{\varphi }^{\prime })}{2n}}\right)F\left(kL{a}^{-}(\varphi -{\varphi }^{\prime })\right)$		(154)
	$D_3$	$={\displaystyle \frac{-e^{-\frac{j\pi }{4}}}{2n\sqrt{2\pi k}\sin ({\beta }_0)}}\text{cot}\left({\displaystyle \frac{\pi +(\varphi +{\varphi }^{\prime })}{2n}}\right)F\left(kL{a}^{+}(\varphi +{\varphi }^{\prime })\right)$		(155)
	$D_4$	$={\displaystyle \frac{-e^{-\frac{j\pi }{4}}}{2n\sqrt{2\pi k}\sin ({\beta }_0)}}\text{cot}\left({\displaystyle \frac{\pi -(\varphi +{\varphi }^{\prime })}{2n}}\right)F\left(kL{a}^{-}(\varphi +{\varphi }^{\prime })\right)$		(156)

where

	$L$	$={\displaystyle \frac{s{s}^{\prime }}{s+s^{\prime }}}{\sin }^2({\beta }_0)$		(157)
	$a^{\pm }(\beta )$	$=2{\cos }^2\left({\displaystyle \frac{2n\pi N^{\pm }-\beta }{2}}\right)$		(158)
	$N^{\pm }$	$=\text{round}\left({\displaystyle \frac{\beta \pm \pi }{2n\pi }}\right)$		(159)
	$F(x)$	$=2j\sqrt{x}{e}^{jx}{\displaystyle {\int }_{\sqrt{x}}^{\mathrm{\infty }}}{e}^{-j{t}^2}𝑑t$		(160)

and $\text{round}(\cdot )$ is the function that rounds to the closest integer. The function $F(x)$ can be expressed with the help of the standard Fresnel integrals [40].

	$S(x)$	$={\displaystyle {\int }_0^x}\sin \left(\pi t^2/2\right)𝑑t$		(161)
	$C(x)$	$={\displaystyle {\int }_0^x}\cos \left(\pi t^2/2\right)𝑑t$		(162)

as

$$F(x)=\sqrt{\frac{\pi x}{2}}{e}^{jx}\left[1+j-2\left(S\left(\sqrt{2x/\pi }\right)+jC\left(\sqrt{2x/\pi }\right)\right)\right].$$

(163)
